Macro Reference
366
Vision System FH/FZ5 Series
User’s Manual (Z340)
List of Figure Numbers
To set or acquire a model figure or region figure held in a processing unit, specify the number of the figure to be
set or acquired. The figure numbers and figures of each processing item are shown below.
Wide arc 256
figure(0) Figure data header information
figure(1) Figure type information
figure(2) X-coordinate of center
figure(3) Y-coordinate of center
figure(4) Radius
figure(5) Start angle
figure(6) End angle
figure(7) Width
Polygon 512
figure(0) Figure data header information
figure(1) Figure type information
figure(2) Number of vertexes
figure(3) First point X
figure(4) First point Y
figure(5) Second point X
figure(6) Second point Y
.
.
.
.
.
.
figure(19) 9th point X
figure(20) 9th point Y
figure(21) 10th point X
figure(22) 10th point Y
Parameter
Figure
number
Description
Search
0 Model registration figure (model registration)
1 Measurement region figure (region setting)
Flexible Search
0 Model registration figure for model 0 (model registration)
1 Model registration figure for model 1 (model registration)
2 Model registration figure for model 2 (model registration)
3 Model registration figure for model 3 (model registration)
4 Model registration figure for model 4 (model registration)
5 Measurement region figure (region setting)
Sensitive Search
0 Model registration figure(model registration)
1 Measurement region figure (region setting)
Figure
Figure
kind
Array
element
Description
