About Limits on the Number of Image Input Processing Items Used
858
Vision System FH/FZ5 Series
User’s Manual (Z340)
About Limits on the Number of Image Input Processing Items Used
For the FZ5-L3@@/6@@ series, The number of image input processing items that can be used within one scene
is limited by the combinations of the camera. (Units that are not used in conditional branching, etc. are also
targeted.)
If the limit is exceeded, a measurement NG occurs due to a memory shortage during measurement.
Please use within this processing items limitation.
Image input related processing items
Target processing items are as follows.
*1: When using a Polar Transformation, each image input related unit after Polar Transformation may consume up to a maximum
of 2 items.
*2: For each unit, 4 items are consumed for Advanced Filter.
*3: Image file display consumes the number of image setting value items per unit.
*4: Display Last NG Image consumes the number of save setting value items per unit.
Camera used
Number of image input related
processing item restriction
0.3 megapixel color camera 81
0.3 megapixel monochrome camera 245
Intelligent compact camera (FZ-SQ) 69
2 megapixel color camera 13
2 megapixel monochrome camera 39
5 megapixel color camera 6
5 megapixel monochrome camera 19
Item Processing item Item Processing item
Loading Images
Camera Image Input
Performing image
compensation
Anti Color Shading
Camera Image Input HDR Stripes Removal Filter II
Camera Switching Polar Transformation
(*1)
Camera Image Input FH Image Subtraction
Camera Image Input HDR Lite Advanced Filter
(*2)
Performing image
compensation
Position Compensation Machine Simulator
Filtering Panorama
Background Suppression Trapezoidal Correction
Brightness Correct Filter
Image Subtraction Panorama
Precise Calibration
Reference Calib Data
Color Gray Filter
Display results
Display Image File
(*3)
Extract Color Filter Display Last NG image
(*4)
• If there is one or more "Sensitive Search" in the flow, the number of image input items that can be used is only reduced
by one.
• In the case of the FH/FZ5-11@@, the number of processing items is not limited and can be registered as long as there is
sufficient free memory. Note, however, that a warning message is displayed when the available memory drops to below
1 GB. In this case, adjust the inspection flow to ensure at least 1 G of available memory.
IMPORTANT
