Setting the Operation Mode
281
7
Changing the System Environment
Vision System FH/FZ5 Series
User’s Manual (Z340)
*1: The [Subt./Reg.] and [DI Register] measurement modes are not supported.
*2: Re-measured images in Non-Stop Adjustment Mode are logged.
*3: Sensor Controller in Non-Stop Adjustment Mode does not stand by.
High-speed Logging Mode
Normally, the sensor controller executes measurements, image logging, and image display in a designated
order. The FH and FZ5-11-series controllers execute those processes with one of the CPU cores, and uses
the rest of the cores for measurement processing. This ensures that measurements are always processed at
maximum performance.
Scan Edge Width OK Precise Calibration OK Control Flow Parallel RST(*3)
Circular Scan Edge Position OK User Data OK Control Flow Fieldbus RST(*3)
Circular Scan Edge Width OK Set Unit Data OK Selective Branch OK
Color Data OK Get Unit Data OK Data Output OK
Gravity and Area OK Set Unit Figure OK Parallel Data Output OK
Labeling OK Get Unit Figure OK Parallel Judgement Output OK
Label Data OK Trend Monitor --- Fieldbus Data Output OK
Defect OK Image Logging OK Result Display OK
Precise Defect OK Image Conversion Logging RST(*2) Display Image File OK
Fine Matching OK Data Logging RST(*2) Display Last NG Image OK
Character Inspection OK Elapsed Time OK OCR OK
Date Verification OK Wait OK OCR User Dictionary OK
Model Dictionary OK Focus OK
2D Codes OK Iris OK
Circle Angle OK Unit Macro OK
Shape Search III OK Unit Calculation Macro OK
Intersection OK Parallelize OK
Barcode OK Parallelize Task OK
OK:Supported processing item, RST: Processing item with restricted support, ---:Unsupported processing item
Processing item Support Processing item Support Processing item
