Windows

Vision System FH/FZ5 Series

User’s Manual (Z340)

Menu List

The menu for the Main Window is described below.

Main menu Command Description Reference

File End

Exits the FH/FZ5 System.

After you exit the system, restart the system or turn OFF

the power supply.

---

Function

Measure

Executes a test measurement (single or continuous

measurement), or a re-measurement.

Reference: Executing

Test Measurements (p.74)

Reference: Remeasuring

Saved Images (p.109)

Scene switch

This button switches between scene groups and

scenes:

Reference: Changing the

Scene or Scene Group

(p.60)

Scene maintenance

Used to copy, delete, and rename scenes and scene

groups.

Reference: Editing

Scenes (p.62)

Reference: Editing

Scene Groups (p.64)

Edit flow Used to edit measurement flows.

Reference: Editing

Processing Units in Scenes

(p.53)

Switch layout Changes the layout number to display.

Reference: Arranging

Window Elements (Layout

Modification) (p.78)

Clear measurement Clears the measurement data.

Reference: Clearing

Measurement Results

(p.122)

Clear logging image Clears the images that are logged in the Controller.

Reference: Clearing

Saved Images (p.123)

Screen capture Captures the screen that is being displayed.

Reference: Capturing

Screen Images (p.123)

Saving last logging


Logs the most recent input images that are being

displayed.

Reference: Logging

Measurement Values and

Measurement Images

(p.113)

Data save Saves settings data to the flash memory in the FH/FZ5.

Reference: Saving

Settings before Turning

OFF the Power and

Restarting (p.43)

Reference: Saving and

Loading Data (p.253)

Save to file

Saves the settings data, logged images, and logged

data to a file. It also copies files between memory

devices.

Reference: Saving and

Loading Data (p.253)

Load from file Loads a settings file.

System initialization Restores the Controller to the default settings.

Reference: Initializing

the Controller (p.45)

System restart Restarts the Controller.

Reference: Saving

Settings before Turning

OFF the Power and

Restarting (p.43)

Reference: Saving and

Loading Data (p.253)
