Saving Data to the FH/FZ5
255
6
Saving and Loading Data
Vision System FH/FZ5 Series
User’s Manual (Z340)
The following table shows the data that is retained or cleared and the data that is saved when the power supply
is turned OFF.
*1: If images are being logged by the system, select [Other] − [Logging setting] under the System Settings and set the destination
for logged images to [Save to memory].
*2: If images are being logged by the system, select [Other] − [Logging setting] under the System Settings and set the destination
for logged images to [Save to memory + file].
External Drive Names
Drive Names for USB Devices
The Controller has four USB connectors. If more than one USB memory device is inserted, specify the USB
memory drive that is to be the destination.
•FZ5-L3 or FZ5-6
The drive names of USB memory devices are USBDisk, USBDisk2, USBDisk3 and USBDisk4 according to the sequence
in which devices are inserted into the Controller.
If the Controller, however, is started with more than one USB memory device inserted, drive names will be assigned based
on the ports in which the USB memory devices are inserted. Depending on the Controller type, USB memory devices are
recognized and drive name are assigned using the following sequence.
• Controller with Integrated Panel
1: Left side on the front - 2: Right side on the front - 3: Front on the side - 4: Back on the side
• Box-type Controller
1: Lower left on the front - 2: Lower right on the front - 3: Upper left on the front - 4: Upper right on the front
• FH or FZ5-11
USB devices are assigned as drives E:\, F:\, G:\ and H:\ in the order in which they are inserted.
Saving area
At power
OFF
Target data
Settings data
(system data,
scene data, and
scene group data)
Logged
images
Last input
image and last
NG image
Logged data
(measure-
ment data)
Capture
Sensor
Controller
Flash memory
of the Controller
Retained OK ---
--- --- ---
Controller
memory (RAM)
Cleared --- OK
*1
RAM disk Cleared
OK OK
*2
OK OK OK
External
memory
USB memory
Retained
SD Memory
Card
Shared folder
on a computer
connected to
the network
During data transfer, do not turn OFF the power supply.
• When a message indicating that processing such as saving or loading is in progress is displayed, do not restart the
Controller or turn OFF the power supply. Data will be corrupted and the system will not work properly at the next startup.
• Do not remove external memory devices while data is being saved or loaded. The operation of the Controller may
corrupt the data or external memory.
• Do not change the file name extension of saved files. If you change the extension, the file cannot be loaded as setting
data. In addition, if setting data in which the extension was changed is loaded, the system may not work properly later.
• Depending on the settings, saving may fail due to insufficient external memory space. If saving fails and the error
message “Please check” appears, check to see if there is unnecessary data in the external memory and save the data
after the unnecessary data has been deleted.
