Using NG Analyzer
133
4
Using Tools
Vision System FH/FZ5 Series
User’s Manual (Z340)
Layout of NG Analyzer Window
a. Analysis result display area
1. Image display area
Displays selected images.
2. Image selection
Selects the image number to be displayed in the image display area.
a
b
1
2
3
1. List of units
A list of units currently set is shown together with analysis
results.
2. Details of unit
Detailed analysis results of each unit are shown.
3. Details of data
Detailed results of analysis data are shown.
1
1. Display ratio
Sets magnification to display.
12
