Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Target figure for the processing unit figure setting has disappeared
This occurs when image input or image compensation-related units, such as filtering, are set
between the processing unit figure setting and the unit to be changed.
Processing Items List Manual
Processing Item List > Supporting Inspection and Measurement > Processing Unit Figure
Setting
Refer to the [Important] section of the aforementioned.
Judgement (JG) value is -10
The judgement will be -10 when there is incompatibility between the scene setting and the
input image. Could the image be a color image even though it is loaded to a scene that is set
for a monochrome camera? Please check the setting.
About Parallel Interface
Trigger signal (input signal) not accepted
Are the cables connected correctly?
Is the signal cable disconnected?
You can check the communication status in the Confirmation window.
Reference: Parallel Communications - Testing Communications in the Vision System FH/FZ5 Series
User's Manual for Communications Settings (Cat No. Z342)
Are windows other than the Main screen (the Edit Flow window, etc.) displayed?
Are there any setting windows open?
* A setting window is defined as a window that opens separately such as the Edit Flow window and the
Scene Maintenance window.
Signals cannot be output to external devices
Is the trigger signal input?
Are the cables connected correctly?
Is the signal cable disconnected?
You can check the communication status in the Confirmation window.
Reference: Parallel Communications - Testing Communications in the Vision System FH/FZ5 Series
User's Manual for Communications Settings (Cat No. Z342)
Is test measurement being performed?
Data cannot be output to external devices during test measurement.
GATE signals are not output
Wiring:
Are parallel cables wired correctly?
Please check if GATE signals are being recognized by the receiving side (such as the PLC) by turning the
GATE signal ON/OFF in the System - Communication - Parallel - Confirmation window.
Output setting:
Is parallel judgement output or parallel data output set for the scene? Is an expression input
for parallel data output?
GATE signals are not output unless these items are specified.
Is [Output] set to ON in the layout setup?
Set whether to produce external outputs for each layout.
Timing:
Are the parallel communication settings (output cycle and output time) set to a length
sufficient for the PLC to recognize?
