About Max. Number of Loading Images during Multi-input
859
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
About Max. Number of Loading Images during Multi-input
The function that enables continuous high speed image input is called the multi-input function.
The maximum number of images that can be loaded based on each specification is shown below.
Type of controller 0.3 megapixel camera 2 megapixel camera 5 megapixel camera
FZ5-L3@@
16 (for cameras 0 and 1)
32 (for cameras 2 and 3)
4 (for cameras 0 and 1)
8 (for cameras 2 and 3)
1 (for cameras 0 and 1)
2 (for cameras 2 and 3)
FZ5-6@@ 32 8 2
FZ5-11@@ 32 8 2
FH-1@@@
FH-3@@@
256 64 25
Type of controller 0.3 megapixel camera 2 megapixel camera 4 megapixel camera 12 megapixel camera
FZ5-L3@@ --- --- --- ---
FZ5-6@@ --- --- --- ---
FZ5-11@@ --- --- --- ---
FH-1@@@
FH-3@@@
256 51 32 10
• The multi-input function cannot be used when the built-in lighting of an intelligent compact camera, FZ-SQ@@@@, is
used.
• The maximum number of images loaded does not change even if partial reading of camera images is selected.
• When using two camera cables for connection, the maximum number of loaded images during multi-input is twice the
number given in the table.
