Macro Reference
369
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Model Number List
When you need to re-register the processing unit model, specify the number of the model to be
re-registered. The model numbers and models of each processing item are shown below.
Advanced filter 0 Measurement region figure (region setting)
Panorama --- No figure
Trapezoidal Correction + 0 Measurement region figure (region setting)
Stripes Removal Filter + 0 Measurement region figure (region setting)
Halation suppression + 0 Measurement region figure (region setting)
Parameter
Modle
number
Description
Search 0 Search model
Flexible Search
0 Index 0, model 0 search model
1 Index 0, model 1 search model
2 Index 0, model 2 search model
3 Index 0, model 3 search model
4 Index 0, model 4 search model
Sensitive Search 0 Search model
ECM Search 0 Search model
EC Circle Search 0 Search model
Shape Search II 0 Search model
Shape Search III 0 Search model
Ec Corner 0 Reference position
Ec Cross 0 Reference position
Classification
0 Index 0, model 0 search model
1 Index 0, model 1 search model
2 Index 0, model 2 search model
3 Index 0, model 3 search model
4 Index 0, model 4 search model
5 Index 1, model 0 search model
6 Index 1, model 1 search model
.
.
.
.
.
.
178 Index 35, model 3 search model
179 Index 35, model 4 search model
180 Index 36, model 0 search model
181 Index 36, model 1 search model
.
.
.
.
.
.
998 Index 199, model 3 search model
999 Index 199, model 4 search model
Parameter
Figure
number
Description
