FAQ
832
Vision System FH/FZ5 Series
User’s Manual (Z340)
"NG (memory shortage)" is displayed in the "Detail result" area
• Does the number of specific processing items, such as camera image input, exceed the limit?
Reference: About Limits on the Number of Image Input Processing Items Used (p.858)
Data cannot be saved
• The data save may have failed because there was not enough free capacity in the flash memory
in the controller. The current scene group data in the controller memory is destroyed after the
restart. Immediately perform one of the recovery/avoidance procedures specified below.
- For example, reduce the memory usage and then save data again to the controller, delete scenes, delete
processing units, adjust the processing unit measurement area, or adjust the sizes of registered models.
- Evacuate the current scene group data to a USB memory.
Click [Function] menu - [Save to file] - [Setting data] - [Scene group data].
The window switching speed is slow.
• When both lines are set to through display in the multi-line random trigger mode, the
controller's response time may be slow.
Remote Operation Tool operation or operation of tools such as the Communications Command
Macro tool is unstable.
• This can occur when there is not enough free application memory space. To free up
application memory space in order to resolve this issue, try deleting processing units to
reduce the number of processing units in the measurement flow.
For FZ5-L35@/6@@ Series models, deleting some of the processing item types registered to
the measurement flow and then saving the data to the Sensor Controller directly and
restarting the system may work to resolve this issue.
The image will not be displayed when remeasuring saved images
• You may be using the through image mode in the image display pane on the used layouts.
If you are used the through image mode in the image display pane, the image will not be
displayed. Check the image mode for all used and unused image display pane.
Refer to "Arranging Windows" (Reference: Image Pane (p.85)) and check the image display mode
specifications for all 24 image display panes.
For Measurement
Display is not updated.
• Measurement is given priority when the STEP signal input interval is short or continuous
measurement is being performed. As a result, the measurement results (overall judgment, image,
individual judgment in the flow display, detailed results) may not be updated. When continuous
measurement ends, the measurement results for the final measurement are displayed.
The measurement NG (image mismatch) error will result when connecting a monochrome camera
• Immediately after performing such operation as starting up the FH/FZ5 Sensor Controller,
changing scenes, and clearing measurement results, there will be no input image. If you edit
the settings or press the OK button in the Properties Dialog Box with no input image, the error
will occur at the next measurement.
• If you open the Properties Dialog Box and click the OK button to close the dialog box with no
input image, the settings will automatically switch to the factory default settings for the color
cameras. If measuring an image input from the monochrome camera with these settings, the
error will result due to the mismatching color modes between the camera and the settings.
• To correct the settings after the error occurrence, input the image from the monochrome
camera and open the Properties Dialog Boxes for each processing unit. Click the OK button
on each screen to exit the screen.
To Next Page
