Macro Reference
374
Vision System FH/FZ5 Series
User’s Manual (Z340)
List of Sub-Image Numbers
In addition to measurement images, the processing unit also contains images being processed and images that
have been processed, and these can be displayed in the image window as sub-images. To display a sub-image,
specify the number of the sub-image. The sub-image numbers and sub-images of each processing item are
shown below.
Item Sub-image Description
Search 0 Measurement image
Flexible Search 0 Measurement image
Sensitive Search 0 Measurement image
ECM Search
0 Measurement image
1 Image with the edge that matches the measurement image overlaid
EC Circle Search 0 Measurement image
Shape Search II 0 Measurement image
Shape Search III
0 Measurement image
1 Display of measurement object and corresponding model.
2 Edge image
3 Display of edge image and corresponding model
Ec Corner 0 Measurement image
Ec Cross 0 Measurement image
Classification 0 Measurement image
Edge Position
0 Measurement image
1 Profile image
Edge Pitch
0 Measurement image
1 Profile image
Scan Edge Position
0 Measurement image
1 Scan image
Scan Edge Width
0 Measurement image
1 Scan image
Circular Scan Edge Position
0 Measurement image
1 Edge position display image of each divided region
Circular Scan Edge Width
0 Measurement image
1 Edge position image of each region division
Intersection
0 Measurement image
1 Scan region image
Color Data
0 Measurement image
1 Masked image
Gravity and Area
0 Measurement image
1
Color extraction image (when measuring a color image)
Binary image (when measuring a monochrome image)
Labeling
0 Measurement image
1
Color extraction image (when measuring a color image)
Binary image (when measuring a monochrome image)
Label Data 0 Measurement image
