Macro Reference
341
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
List of I/O Modules
I/O module settings required for communication with external devices are indicated below.
EtherNetIP
EtherNet/IP Interface communication
IoModule identification name
EtherNetIP
Overview
This is a module is for sending and receiving commands and data by Ethernet/IP protocol.
System data
Supported functions
Identification name IO module name References
EtherNetIP EtherNet/IP Interface communication Reference: Details (p.341)
ParallelIo Parallel Interface communication Reference: Details (p.343)
SerialNormal
SerialNormal2 (Fxxx series method)
Serial Interface Normal communication Reference: Details (p.344)
SerialPlcLinkM
Serial Interface PLC Link (MELSEC QnU/Q/QnAS)
communication
Reference: Details (p.346)
SerialPlcLink
Serial Interface PLC Link (SYSMAC CS/CJ/CP/
One) communication
Reference: Details (p.348)
TcpClient TCP Client Normal communication Reference: Details (p.351)
TcpNormal TCP Normal communication Reference: Details (p.352)
UdpNormal
UdpNormal2 (Fxxx series method)
UDP Normal communication Reference: Details (p.354)
UdpPlcLinkM PLC Link (MELSEC QnU/Q/QnAS) communication Reference: Details (p.356)
UdpPlcLinkY PLC Link (JEPMC MP) communication Reference: Details (p.358)
UdpPlcLink
PLC Link (SYSMAC CS/CJ/CP/One)
communication
Reference: Details (p.361)
Identification Meaning Initial value
handshake
Output control
0: OFF
1: Handshaking
0
cycleTime Output period [ms] 100
outputTime Output time [ms] 50
timeout Timeout [s] 100
IoInitialize OK ---
GetPort OK Reference: GetPort (p.542)
PutPort OK Reference: PutPort (p.645)
