Macro Reference
361
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
UdpPlcLink
PLC Link (SYSMAC CS/CJ/CP/One) communication
IoModule identification name
UdpPlcLink
Overview
This is a module is for sending and receiving commands and data by Ethernet PLC Link protocol.
System data
PLC Link data
Identification Meaning Initial value
enableDhcp
Enable DHCP
0: Disabled
1: Enabled
0
ipAddress IP address of the system 10.5.5.100
subnetMask Subnet mask 255.255.255.0
defaultGateway Gateway address 10.5.5.110
dns DNS server DNS server address 10.5.5.1
delayCount Output IP address 0.0.0.0
portNo Input port No. 9600
Identification Meaning Initial value
commandArea Command area Area CIO Area (CIO)
commandMemoryAddress Command area Address 0
responseArea Response area Area CIO Area (CIO)
responseMemoryAddress Response area Address 100
outputArea Data Output area Area CIO Area (CIO)
outputMemoryAddress Data Output area Address 200
handshake Handshaking 1
responseTimeout Retry interval [ms] 10000
responseTimeout2 Retry interval 2 [ms] 1000
