Saving Settings Data to the Flash Memory and
Restarting
257
6
Saving and Loading Data
Vision System FH/FZ5 Series
User’s Manual (Z340)
Saving Settings Data to the Flash Memory and Restarting
This section describes the procedure to save settings data (system data, scene data, and scene group data) in
the flash memory of the Sensor Controller. Make sure to save setting data when settings have been changed.
Every time you restart the Sensor Controller, the data in the memory is loaded and enabled.
1 For the FZ5-L3 or FZ5-6, insert an external memory device into the Controller before
you save the data for scene groups 1 to 31.
2 Click [Save to file] on the toolbar in the
Main Window.
A confirmation message is displayed.
3 Click [OK].
For the FZ5-L3 or FZ5-6, system data and data from scene group 0 are saved to the Controller’s
flash memory and the data from scene groups 1 to 31 is saved to the external memory.
For the FH or FZ5-11, all data is saved in the flash memory in the Controller by default.
If more than one USB memory device is connected to the Controller, check in the File Explorer to confirm
that the external memory device where the scene group data is to be saved is recognized as the USB
disk.
Reference: External Drive Names (p.255)
• If [Save to file] is performed for [System + scene group 0 data], the data being saved will also be saved to the Controller’s
flash memory at the same time. Do not turn OFF the power supply during this process. The Controller may not start up
properly the next time it is turned ON.
• During data transfer to external memory, do not remove the external memory device until the transfer is completed. Data
and the external memory may be corrupted.
If an external memory device is not inserted, a confirmation message is displayed.
If [OK] is clicked, only system data and data from scene group 0 are saved in the Controller’s flash memory.
Note
To Next Page
