Editing Scene Groups
65
2
Setting Scenes (Measurement Flows)
Vision System FH/FZ5 Series
User’s Manual (Z340)
9 Click the [Close] button.
Changing the Scene Group Name
Scene groups can be named with any desired text. This is convenient to make scene groups easier to identify
when there are many scene groups to manage.
1 In the Main Window (layout 0), select [Scene maintenance] from the [Function] menu.
The [Scene maintenance] dialog box is displayed.
2 Click the [Rename] button.
The [Scene group maintenance] dialog box is
displayed.
3 Click [...] next to [Scene group name].
The on-screen keyboard is displayed.
4 Set the name.
Enter 15 characters or less.
5 Click [OK].
6 Click the [Close] button.
