Macro Reference
340
Vision System FH/FZ5 Series
User’s Manual (Z340)
Logging setting
Destination
Specify the image file save destination (RAM disk or USB
memory).
imageLoggingDirectory
Prefix imageLoggingHeader
Switch saving folder by scene
0: Disabled
1: Enabled
imageLoggingScene
Switch saving folder by judge
0: Disabled
1: Enabled
imageLoggingJudge
Logging priority
0: Give priority to logging
1: Give priority to measurement takt
imageLoggingPriority
Data Logging
0: None
1: Save for only NG
2: All
dataLogging
Destination folder name dataLoggingDirectory
User definition --- PanDA
Identifier information 0 Identifier information 1 Data identifier name
