Macro Reference
339
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Other
--- Trigger
STEP signal filter width
5: 100
11: 200
18: 300
24: 400
30: 500
digitalFilter
Use Encoder trigger
0: Not used
1 : Used
encoderEnabled
Encoder input selection
0: Open collector
1: Line driver
encoderInputPulse
Phase A resolution encoderResolutionA
Count rotations with phase Z
0: Do not count
1: Count
encoderZ
Encoder start encoderStart
Encoder count encoderCount
Phase A trigger timing usage flag 0 encoderTriggerAngleA0
Phase A trigger timing usage flag 1 encoderTriggerAngleA1
Phase A trigger timing usage flag 2 encoderTriggerAngleA2
Phase A trigger timing usage flag 3 encoderTriggerAngleA3
Phase A trigger timing usage flag 4 encoderTriggerAngleA4
Phase A trigger timing usage flag 5 encoderTriggerAngleA5
Support backlashing (phase B)
0: Do not support
1: Support
encoderBacklash
Trigger in backlashing
0: Do not generate
1: Generate
encoderBacklashTrigger
Phase A encoderTriggerCountA
Phase Z encoderTriggerCountZ
Network drive setting
--- NetworkDrive
S drive0
T drive1
U drive2
V drive3
W drive4
X drive5
Y drive6
Z drive7
Logging setting
--- Logging
Image Logging
0: None
1: Save for only NG
2: All
imageLogging
Identifier information 0 Identifier information 1 Data identifier name
