Macro Reference
338
Vision System FH/FZ5 Series
User’s Manual (Z340)
EtherCAT
Data output number for line 6 (number of data output items
for line 6)
32: Result Data Format 0 (8 DINT)
64: Result Data Format 1 (16 DINT)
128: Result Data Format 2 (32 DINT)
256: Result Data Format 3 (64 DINT)
2097152: Result Data Format 4 (4 LREAL)
4194304: Result Data Format 5 (8 LREAL)
8388608: Result Data Format 6 (16 LREAL)
16777216: Result Data Format 7 (32 LREAL)
1572872: Result Data Format 8 (2 DINT + 3 LREAL)
3145744: Result Data Format 9 (4 DINT + 6 LREAL)
6291488: Result Data Format 10 (8 DINT + 12 LREAL)
12582976: Result Data Format 11 (16 DINT + 24 LREAL)
outputDataSize6
Data output number for line 7 (number of data output items
for line 7)
32: Result Data Format 0 (8 DINT)
64: Result Data Format 1 (16 DINT)
128: Result Data Format 2 (32 DINT)
256: Result Data Format 3 (64 DINT)
2097152: Result Data Format 4 (4 LREAL)
4194304: Result Data Format 5 (8 LREAL)
8388608: Result Data Format 6 (16 LREAL)
16777216: Result Data Format 7 (32 LREAL)
1572872: Result Data Format 8 (2 DINT + 3 LREAL)
3145744: Result Data Format 9 (4 DINT + 6 LREAL)
6291488: Result Data Format 10 (8 DINT + 12 LREAL)
12582976: Result Data Format 11 (16 DINT + 24 LREAL)
outputDataSize7
EtherNet/IP
--- EtherNetIP
Output control
0: OFF
1: Handshaking
handshake
Output cycle cycleTime
Output time outputTime
Timeout timeout
measurement
--- Measure
Fan control setting
0: Slow rotation
1: Fast rotation
fanControl
Destination folder captureDirectory
STEP in measure
0: ERROR signal output OFF for STEP input during
measurement
1: ERROR signal output ON for STEP input during
measurement
stepError
Scene group switch
0: Do not save when changing scene group
1: Save when changing scene group
sceneGroupSave
Scene switch time sceneWaitTime
Identifier information 0 Identifier information 1 Data identifier name
