Macro Reference
356
Vision System FH/FZ5 Series
User’s Manual (Z340)
UdpPlcLinkM
PLC Link (MELSEC QnU/Q/QnAS) communication
IoModule identification name
UdpPlcLinkM
Overview
This is a module is for sending and receiving commands and data by Ethernet PLC Link protocol.
System data
PLC Link data
Area classification
Identification Meaning Initial value
enableDhcp
Enable DHCP
0: Disabled
1: Enabled
0
ipAddress IP address of the system 10.5.5.100
subnetMask Subnet mask 255.255.255.0
defaultGateway Gateway address 10.5.5.110
dns DNS server 10.5.5.1
delayCount Output IP address 0.0.0.0
portNo Input port No. 9600
Identification Meaning Initial value
commandArea Command area Area Data register
commandMemoryAddress Command area Address 0
responseArea Response area Area Data register
responseMemoryAddress Response area Address 100
outputArea Data Output area Area Data register
outputMemoryAddress Data Output area Address 200
handshake Handshaking 1
responseTimeout Retry interval [ms] 10000
responseTimeout2 Retry interval 2 [ms] 1000
Area classification name Area classification number
Data register 168
File register 175
Link register 180
