Macro Reference
352
Vision System FH/FZ5 Series
User’s Manual (Z340)
Example
Receive data.
Set an IP address and parameter size (*4 integer type domain) in a parameter to use an Ethernet.
Send data
Set an IP address and parameter size (*4 integer type domain) in a parameter to use an Ethernet.
TcpNormal
TCP Normal communication
IoModule identification name
TcpNormal
Overview
This is a module is for sending and receiving commands and data by Ethernet TCP protocol.
System data
Dim data&(256)
Dim ipaddr&(4)
'Set the IP address of the destination.
ipaddr&(0) = 10
ipaddr&(1) = 5
ipaddr&(2) = 5
ipaddr&(3) = 101
'Gets the five data.
ReceiveData "TcpClient", data&(), 4*5, size&, ipaddr&(), 4*4
Dim data&(256)
Dim ipaddr&(4)
'Set the IP address of the destination.
ipaddr&(0) = 10
ipaddr&(1) = 5
ipaddr&(2) = 5
ipaddr&(3) = 101
'Transmit the five data.
SendData "TcpClient", data&(), 4*5, ipaddr&(), 4*4
Identification Meaning Initial value
enableDhcp
Enable DHCP
0: Disabled
1: Enabled
0
ipAddress IP address of the system 10.5.5.100
subnetMask Subnet mask 255.255.255.0
defaultGateway Default gateway 10.5.5.110
dns DNS server address 10.5.5.1
portNo Port number to receive commands 9600
