Macro Reference
358
Vision System FH/FZ5 Series
User’s Manual (Z340)
Set data to writeData().
Write in data for 7ch from 10ch of the DM area.
UdpPlcLinkY
PLC Link (JEPMC MP) communication
IoModule identification name
UdpPlcLinkY
Overview
This is a module is for sending and receiving commands and data by Ethernet PLC Link protocol.
PLC Link data
Dim readData&(256)
Dim data3$(21)
'Gets the data from PLC
ReadPlcMemory "UdpPlcLinkM", 168, 10, 7, readData&()
'Gets the data of the real number type
GetPlcData "UdpPlcLinkM", readData&(), 0, 8, data1#
'Gets the data of the integer type
GetPlcData "UdpPlcLinkM", readData&(), 8, 4, data2&
'Gets the data of the character type
GetPlcData "UdpPlcLinkM", readData&(), 12, 5, data2&
Dim writeData&(256)
'Set the data (123.45) of the real number type.
SetPlcData "UdpPlcLinkM", writeData&(), 0, 8, 123.45
'Set the data (20) of the integer type.
SetPlcData "UdpPlcLinkM", writeData&(), 32, 4, 20
'Set the data (OMRON) of the character type.
SetPlcData "UdpPlcLinkM", writeData&(), 36, 5, "OMRON"
'Write in data for 7ch from 10ch of the Data register area.
WritePlcMemory "UdpPlcLinkM", 168, 10, 7, writeData&()
Identification Meaning Initial value
enableDhcp
Enable DHCP
0: Disabled
1: Enabled
0
ipAddress IP address 10.5.5.100
subnetMask Subnet mask 255.255.255.0
defaultGateway Gateway address 10.5.5.110
dns DNS server address 10.5.5.1
delayCount Output IP address 0.0.0.0
portNo Input port number 9600
