Omron SYSMAC FH Series

WWW.NNC.IR
Macro Reference
354
Vision System FH/FZ5 Series
User’s Manual (Z340)
UdpNormal
TCP Normal communication
IoModule identification name
UdpNormal
UdpNormal2 (Fxxx series method)
Overview
This is a module is for sending and receiving commands and data by Ethernet UDP protocol.
System data
(*) If the input port number and the output port number are the same setting, set the output port number to -1.
Supported functions
Identification Meaning Initial value
enableDhcp
Enable DHCP
0: Disabled
1: Enabled
0
ipAddress IP address of the system 10.5.5.100
subnetMask Subnet mask 255.255.255.0
defaultGateway Gateway address 10.5.5.110
dns DNS server address 10.5.5.1
destIpAddress Destination IP address to send data 0.0.0.0
portNo Port number to receive commands 9600
portNo2 Port number to send data -1
IoInitialize OK ---
GetPort OK Reference: GetPort (p.542)
PutPort OK Reference: PutPort (p.645)
BusyOut --- ---
JudgeOut --- ---
RunOut --- ---
GetAll OK Reference: GetAll (p.528)
PutAll OK Reference: PutAll (p.643)
ReceiveData OK Reference: ReceiveData (p.651)
SendData OK Reference: SendData (p.696)
SendString OK Reference: SendString (p.698)
ReadPlcMemory --- ---
WritePlcMemory --- ---
SetPlcData --- ---
GetPlcData --- ---
