SerialPlcLink
Serial Interface PLC Link (SYSMAC CS/CJ/CP/One) communication
IoModule identification name
SerialPlcLink
Overview
This is a module is for sending and receiving commands and data via the serial PLC Link interface.
System data
PLC Link data
Identification Meaning Initial value
rsMode
Interface
0: RS-232C
1: RS-422
0
baudRate Baud rate [bps] 9600
byteSize
Data length [bit]
7 or 8
7
parity
Parity
0: None
1: Odd number
2: Even number
2
stopBits
Stop bits [bit]
0: 1
1: 2
1
softFlow
Flow control
0: None
1: Xon/Xoff
0
timeout Timeout [s] 5
Identification Meaning Initial value
commandArea Command area Area CIO Area (CIO)
commandMemoryAddress Command area Address 0
responseArea Response area Area CIO Area (CIO)
responseMemoryAddress Response area Address 100
outputArea Data Output area Area CIO Area (CIO)
outputMemoryAddress Data Output area Address 200
handshake Handshaking 1
responseTimeout Retry interval [ms] 10000
