Macro Reference
375
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Defect
0 Measurement image
1 Masked defect profile image (with area measurement)
Precise Defect
0 Measurement image
1 Masked defect profile image (with area measurement)
Fine Matching
0 Measurement image
1 Difference image
Character Inspection 0 Measurement image
Date Verification 0 Measurement image
Model Dictionary 0 Measurement image
2DCode 0 Measurement image
Barcode 0 Measurement image
OCR 0 Measurement image
OCR User Dictionary 0 Measurement image
Circle Angle 0 Measurement image
Glue Bead Inspection
0 Measurement image
1 All-color extraction image / Selection color image / Binary image
3 Binary image (route displayed when model is registered)
4 Binary image
Shape Search + 0 Measurement image
Advanced labeling +
0 Measurement image
1
Color extraction image (when measuring a color image)
Binary image (when measuring a monochrome image)
Barcode + 0 Measurement image
2DCode + 0 Measurement image
Camera Image Input 0 Camera image
Camera Image Input FH 0 Camera image
Camera Image Input HDR 0 Camera image
Camera Image Input HDR Lite 0 Camera image
Camera Switching 0 Camera image
Measurement Image Switching
0 Image after switching
1 Measurement image
Position Compensation
0 After scroll
1 Before scroll
Filtering 0 Filtered image
Background Suppression 0 Background suppressed image
Brightness Correct Filter 0 Brightness corrected image
Color Gray Filter 0 Color gray image
Extract Color Filter
0 Color extracted image
1 Measurement image
Anti Color Shading 0 Anti color shading image
Stripes Removal Filter II 0 Color extracted image
Item Sub-image Description
