Outputting a List of Scene Data Set Values
144
Vision System FH/FZ5 Series
User’s Manual (Z340)
Double-byte characters are enclosed in the double quotation marks (").
Refer to the individual processing items and the external reference tables in the Vision System FH/FZ5 Series
Processing Item Function Reference Manual (Cat No. Z341) for the parameters for all data. Only data that can
be read and written can be downloaded.
Output Example of CSV File:
SceneTitle Scene 0
#0 Camera image Camera Image Input
#1 Search Search
outputCoordinate Output coordinates 0
calibration Calibration 0
overallJudge Reflect to overall judgement 0
searchMode Search mode 0
rotation With/without rotation 0
endAngle Upper limit of the rotation angle 180
startAngle Lower limit of the rotation angle −180
angleSkip Skipping angle 5
smartMode Smart mode 1
stability Stab.(CR) 12
accuracy Prec. 2
searchSpeed Stab.(PT) 3
referencePosX Reference X 0
referencePosY Reference Y 0
detectionPosX Detection point X 0
detectionPosY Detection point Y 0
subPixel Sub-pixel 0
candidateLevel Candidate Point Level 70
upperX Upper limit of measure X 99999.9999
lowerX Lower limit of measure X −99999.9999
upperY Upper limit of measure Y 99999.9999
lowerY Lower limit of measure Y −99999.9999
upperAngle Upper limit of the angle 180
lowerAngle Lower limit of the angle −180
upperCorrelation Upper limit of corr. 100
lowerCorrelation Lower limit of corr. 60
savemdlimg Save registered model 0
thersDetail Candidate Point Level 75
sort Sort condition 1
searchNo Search No. 0
upperCount Upper limit of count judgement 32
lowerCount Lower limit of count judgement 0
isMulti Multiple output 0
