Basic Knowledge For Macro Customize Functions
174
Vision System FH/FZ5 Series
User’s Manual (Z340)
In the following cases, a macro customize function is used.
In this case
Macro customize
function that is used
Calculation
Use to perform a calculation process that is difficult or cannot be expressed
using a "Calculation" processing item, such as those below.
• Use to execute a calculation process that extends over multiple lines or
contains a logical expression, conditional branch, loop process, or data
setting process
• Use to execute a customized judgement process for calculation results
"Unit Calculation Macro"
processing item
Calculation,
Display result,
Output result
Use to customize or include the following processes that that are difficult or
cannot be expressed with a "Calculation" processing item or a "Unit Calculation
Macro" processing item.
• Display result (graphic display, detailed text display, etc.)
• Output result
• Measurement initialization processing (scene switching, etc.)
"Unit Macro" processing
item
Scene control
Use to perform the following types of scene control in a measurement flow.
• Changing the settings of multiple processing units at once
• Managing the common data of multiple processing units
• Adding/deleting a processing unit
"Scene Control Macro"
tool
Communication
commands
Use to create expansions that are difficult or cannot be expressed with the
standard communication commands, such as those below.
• Not to exist in the standard communication commands.
• To combine multiple communication command functions into a single
communication command
"Communication
Command Macro" tool
Scene
control macro
Scene
control macro
FH/FZ5
Measurement Flows
Camera
Scene
control macro
Image input
Defect
Search
Output Unit
Unit Macro
Unit Calculation
Macro
Scene
Scene
Scene
Communication
command
macro
PLC or other
external device
