Basic Knowledge For Macro Customize Functions
202
Vision System FH/FZ5 Series
User’s Manual (Z340)
Key Points for Test Measurement and Adjustment (Unit Macro)
To increase the speed and precision of measurement, you can adjust the parameters by performing and
checking the results of test measurements.
The following content is displayed in the "Detail result" area as text.
The image specified in the sub image in image display setting is displayed in the image display area.
Key Points for Adjustment
Select the adjustment method referring to the following points.
An error message appears on the console
Nothing happens when [DEL], [BS], [Enter], etc., is clicked
Want to include a line feed code in a string
The "Positions" display is not as desired
Data acquisition sometimes fails during measurement
Check the measurement results that can be displayed and output in "Measurement Results For Which Output
is Possible".
Reference: XExternal Reference Table (Unit Macro) (p.203)
Displayed items Description
Judge Judgement result
Sub image. Explanation of image to be displayed
0 Measurement image
Parameter to be adjusted Troubleshooting
-
Refer to the error messages list.
Reference: X"Appendixes About Macro Functions List of Macro Error Messages" in the
"Vision System FH/FZ5 Series User's Manual (Z340)"
Parameter to be adjusted Troubleshooting
-
Nothing happens while the focus is not on the code window (key entry cursor is not
displayed). Click the position you want to operate, and then click the button.
Parameter to be adjusted Troubleshooting
Macro code Add (+) CR → Chr$(13) LF → Chr$(10) to the string.
Parameter to be adjusted Troubleshooting
Macro code
When "Positions" is OFF, the display processing written in "*MEASUREDISPT" and
"*MEASUREDISPG" is executed. When "Positions" is ON, only what is written in
"*MEASUREDISPG" is displayed.
Parameter to be adjusted Troubleshooting
Macro code
Data may be stolen by the applicable communication processing unless the communication
processing is stopped using the SetPollingState function.
(Example) Receive data without TCP procedure
Write the processing in the following sequence.
• SetPollingState "TcpNormal", false
• Data receive processing
• SetPollingState "TcpNormal", true
