Basic Knowledge For Macro Customize Functions
204
Vision System FH/FZ5 Series
User’s Manual (Z340)
Saving and Loading Programs in the Communication Command Macro
In the communication command macro tool, a program can be saved when "Data save" is executed, and a
standalone program can be saved and loaded in the tool setting screen.
• Saving a program
1 Click [Export] in the file area.
2 Specify the file save location and the file name, and click [OK].
• Loading a program
1 Click [Import] in the file area.
2 Select the saved file (.mcr) that you want to load and click [OK].
Saving and Loading Programs in the Unit Macro
In the "Unit Macro" processing item, programs can be saved and loaded to the scene data as a processing
unit, and in the properties screen of the processing item, standalone programs can be saved and loaded.
• Saving a program
1 Click [Export] in the file area.
2 Specify the file save location and the file name, and click [OK].
• Loading a program
1 Click [Import] in the file area.
2 Select the saved file (.mcr) that you want to load and click [OK].
The programs saved in the communication command macro tool include created programs and programs automatically
generated by the tool. Do not change an automatically generated program. If changed, the program may not load
normally.
IMPORTANT
