Setting the Camera Conditions
266
Vision System FH/FZ5 Series
User’s Manual (Z340)
1 In the Main Window, select [Camera] − [Output Signal Setting] from the [Tool] menu.
The settings dialog box for the output signals is displayed.
2 Select the output signal in the [Common setting] Area.
3 Set SHTOUT for each line in the [Line setting] area.
4 Click the [Close] Button.
• If the [Output Signal Selection] is set to [SHTOUT], the SHTOUT signal is output according to the settings in the
[Individual Line Settings]. If the [Output Signal Selection] is set to STGOUT, the STGOUT signal is output according to
the settings in the [Electronic flash setting] for a camera input processing item.
• When using the Multi-line Random-trigger Mode, the output signal selection can be set only to the output signal setting
for line 0. The settings for line 0 are applied to the other lines.
• If you are using the Camera Image Input HDR, or Camera Image Input HDR Lite processing item, the SHTOUT signal is
output for every image that is taken.
• If you are using the Through Image Mode in the Main Window, the SHTOUT signal is output for every through image that
is taken.
Parameter Set value [Factory default] Description
Output signal
[STGOUT]
The STGOUT signal line is used for the
STGOUT signal. If you selected STGOUT, you
cannot use the SHTOUT output signal.
SHTOUT
The STGOUT signal line is used for the
SHTOUT signal. If you selected SHTOUT, you
cannot use the STGOUT output signal.
Parameter Set value [Factory default] Description
SHTOUT signal delay [μs] [0] to 1,000
Sets the delay time from when exposure is
completed to when the SHTOUT signal turns ON
in increments of 10 μs.
SHTOUT signal pulse width [μs] 40 to 10,000 [5,000]
Sets the time to output the SHTOUT signal in
increments of 10 μs.
SHTOUT signal pulse polarity
• [Positive]
• Negative
Set the polarity of the SHTOUT signal.
Positive: The SHTOUT signal changes from OFF
to ON when the exposure ends.
Negative: The SHTOUT signal changes from ON
to OFF when the exposure ends.
