Setting the Operation Mode
278
Vision System FH/FZ5 Series
User’s Manual (Z340)
The following processing items are supported in the multi-line random trigger mode:
*1: [DI Register] in the measurement mode is not supported.
*2: Not supported for 3 or more lines.
OK:Supported processing item, RST: Processing item with restricted support, ---:Unsupported processing item
Processing item Support Processing item Support Processing item Support
Camera Image Input OK Glue Bead Inspection OK Statistics OK
Camera Image Input FH OK Position Compensation OK Reference Calib Data OK
Camera Image Input HDR OK Filtering OK Position Data Calculation OK
Camera Image Input HDR Lite OK Back Ground Suppression OK Stage Data OK
Camera Switching OK Brightness Correct Filter OK Robot Data OK
Measurement Image
Switching
OK Color Gray Filter OK Vision Master Calibration OK
Search OK Extract Color Filter OK PLC Master Calibration OK
Flexible Search OK Anti-Color Shading OK Convert Position Data OK
Sensitive Search OK Stripes Removal Filter II OK Movement Single Position OK
ECM Search OK Polar Transformation OK Movement Multi Points OK
EC Circle Search OK Trapezoidal Correction OK Detection Point OK
Ec Corner OK Machine Simulator OK Camera Calibration OK
Ec Cross OK Image Subtraction RST(*1) Data Save OK
Shape Search II OK Advanced Filter OK Conditional Branch OK
Classification OK Panorama OK End OK
Edge Position OK Calculation OK DI Branch RST(*2)
Edge Pitch OK Line Regression OK Control Flow Normal OK
Scan Edge Position OK Circle Regression OK Control Flow PLC Link OK
Scan Edge Width OK Precise Calibration OK Control Flow Parallel RST(*2)
Circular Scan Edge Position OK User Data OK Control Flow Fieldbus OK
Circular Scan Edge Width OK Set Unit Data OK Selective Branch OK
Color Data OK Get Unit Data OK Data Output OK
Gravity and Area OK Set Unit Figure OK Parallel Data Output RST(*2)
Labeling OK Get Unit Figure OK Parallel Judgement Output RST(*2)
Label Data OK Trend Monitor OK Fieldbus Data Output OK
Defect OK Image Logging OK Result Display OK
Precise Defect OK Image Conversion Logging OK Display Image File OK
Fine Matching OK Data Logging OK Display Last NG Image OK
Character Inspection OK Elapsed Time OK OCR OK
Date Verification OK Wait OK OCR User Dictionary OK
Model Dictionary OK Focus OK
2D Codes OK Iris OK
Circle Angle OK Unit Macro OK
Shape Search III OK Unit Calculation Macro OK
Intersection OK Parallelize OK
Barcode OK Parallelize Task OK
