Macro Reference
381
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Camera Image
Input HDR
Approx. 3KB
Approx. 9MB (for monochrome image)
Approx. 17MB (for color image)
Model registration figure of calibration
settings, image size, whether image is color
or monochrome.
Camera Image
Input HDR Lite
Approx. 1KB
Approx. 9MB (for monochrome image)
Approx. 17MB (for color image)
Model registration figure of calibration
settings, image size, whether image is color
or monochrome.
Camera Switching Approx. 1KB No change -
Measurement
Image Switching
Approx. 1KB No change -
Position
Compensation
Approx. 1KB Approx. 1MB
Number and length of calculation
expressions
Filtering Approx. 1KB No change -
Background
Suppression
Approx. 1KB No change -
Brightness Correct
Filter
Approx. 1KB No change -
Color Gray Filter Approx. 1KB No change -
Extract Color Filter Approx. 1KB No change -
Anti Color Shading Approx. 1KB No change -
Stripes Removal
Filter II
Approx. 1KB No change -
Polar
Transformation
Approx. 1KB Approx. 1MB
Circle radius, circle width, end point overlay,
image size.
Trapezoidal
Correction
Approx. 1KB Approx. 1MB
Number and length of calculation
expressions
Machine Simulator Approx. 1KB No change -
Image Subtraction Approx. 1KB Approx. 63MB Model registration figure, image size.
Advanced filter Approx. 9KB No change -
Panorama Approx. 240KB Approx. 13MB
Whether brightness correction reference
image is used, image size.
Trapezoidal
Correction +
Approx. 1KB Approx. 1MB
Number and length of calculation
expressions
Stripes Removal
Filter +
Approx. 1KB No change -
Halation
Suppression +
Approx. 1KB No change -
Unit Macro Approx. 1KB Approx. 4MB Length of program code
Unit Calculation
Macro
Approx. 1KB Approx. 2MB Length of program code
Calculation Approx. 1KB Approx. 1MB
Number and length of calculation
expressions, number and length of
comments.
Line Regression Approx. 3KB Approx. 1MB
Number of points, number and length of
calculation expressions
Circle Regression Approx. 2KB Approx. 1MB
Number and length of calculation
expressions
Item
Approximate amount of application memory used
Main settings that affect change of
memory used
Adding to
measurement flow
Change due to settings
