Macro Reference
450
Vision System FH/FZ5 Series
User’s Manual (Z340)
Cos
Gets the cosine of the specified expression.
Format
Cos(<expression>)
Parameter
Return value
Returns the cosine as a double precision real value in the range -1 to 1.
Description
Gets the cosine of the expression specified in the <expression> parameter.
In the <expression> parameter, specify the value in radians. To convert an angle value to a radian value,
multiply by π/180.
If an incorrect data type is specified for a parameter, a "Type mismatch" error will occur.
If a value is assigned to the return value variable or the variable is not used in an expression, a "Syntax error"
error will occur.
If the format is written incorrectly, such as writing the macro function name incorrectly, omitting a comma, or
omitting a half-width space, a "Syntax error" error will occur.
Usage Cautions
• None.
Example
Gets the cosine of 60°.
The result is shown below.
Useable Modules
Unit Calculation Macro / Scene Control Macro / Communication Command Macro / Unit Macro
Supported Versions
Version 3.50 or later
Parameter
name
Data type Description
<expression>
Integer type
Double
precision real
number data
type
Expression to calculate the cosine
DATA# = Cos(60/180*3.141592)
DATA# = 0.5
