LoadSceneGroup
Loads the scene group data.
Format
LoadSceneGroup <sceneGroupNo>, <fileName>
Parameter
Return value
None.
Description
Loads the scene group data file specified in the <fileName> parameter into the scene group number specified
in the <sceneGroupNo> parameter.
In the <fileName> parameter, use an absolute path to specify the file name of the file to be loaded.
In the <fileName> parameter, specify the file name of the scene group data. If a file other than a scene group
data file is specified, an "Illegal function call" error will occur.
If an incorrect data type is specified for a parameter, a "Type mismatch" error will occur.
If a non-existent number, numerical value, or combination of data types or values is specified for a parameter,
an "Illegal function call" error will occur.
If a character string longer than 255 characters is specified for a character string parameter, a "String too
long" error will occur.
If the format is written incorrectly, such as writing the macro function name incorrectly, omitting a comma, or
omitting a half-width space, a "Syntax error" error will occur.
Usage Cautions
• Execute this macro function when the BUSY signal or other measurement in progress signal is ON and
measurement is prohibited. (Reference: XState Transitions and Execution Timing (p.227))
Example
Loads scene data into scene group 2 and then chenges the scene used to scene 0.
Useable Modules
Scene Control Macro / Communication Command Macro
Parameter
name
Data type Description
<sceneGroupNo>
Integer type Scene group number of the destination to read in (0 to 31)
<fileName>
Character
string type
File name of the scene group data to read in (*.sgp)
Rem Load the file of the scene group data.
LoadSceneGroup 2, "C:\BACKDIR\scenegroup02.sgp"
Rem Switch the scene.
ChangeScene 0
