About Lenses
824
Vision System FH/FZ5 Series
User’s Manual (Z340)
• M42 mount Lens 3Z4S-LE VS-MCL/M42 Series for 1.8-inch Image Elements
Lens type
Focal
distance
Aperture
(F No.)
Max. O.D. Full length Filter size
Optical
magnifi-
cation
Depth of
field
3Z4S-LE VS-MCL18/M42-
10
18 mm
F2.8 52 mm dia.
91.5 mm (0.025x) to
96.1 mm (0.25x)
M46
P0.75
0.025x 367.0 mm
0.10x 24.6 mm
0.25x 4.5 mm
3Z4S-LE VS-MCL18-
FN056/M42-10
F5.6 52 mm dia.
91.5 mm (0.025x) to
96.1 mm (0.25x)
M46
P0.75
0.025x 735.0 mm
0.10x 49.3 mm
0.25x 9.0 mm
3Z4S-LE VS-MCL18-
FN080/M42-10
F8 52 mm dia.
91.5 mm (0.025x) to
96.1 mm (0.25x)
M46
P0.75
0.025x 1050.0 mm
0.10x 70.4 mm
0.25x 12.8 mm
3Z4S-LE VS-MCL25/M42-
10
25 mm
F2.6 52 mm dia.
72.0 mm (0.025x) to
82.3 mm (0.40x)
M46
P0.75
0.025x 341.0 mm
0.10x 22.9 mm
0.40x 1.8 mm
3Z4S-LE VS-MCL25-
FN056/M42-10
F5.6 52 mm dia.
72.0 mm (0.025x) to
82.3 mm (0.40x)
M46
P0.75
0.025x 735.0 mm
0.10x 49.3 mm
0.40x 3.9 mm
3Z4S-LE VS-MCL25-
FN080/M42-10
F8 52 mm dia.
72.0 mm (0.025x) to
82.3 mm (0.40x)
M46
P0.75
0.025x 1050.0 mm
0.10x 70.4 mm
0.40x 5.6 mm
3Z4S-LE VS-MCL35/M42-
10
35 mm
F2.8 55 mm dia.
99.5 mm (0.025x) to
117.6 mm (0.50x)
M52
P0.75
0.025x 367.0 mm
0.10x 24.6 mm
0.50x 1.3 mm
3Z4S-LE VS-MCL35-
FN056/M42-10
F5.6 55 mm dia.
99.5 mm (0.025x) to
117.6 mm (0.50x)
M52
P0.75
0.025x 735.0 mm
0.10x 49.3 mm
0.50x 2.7 mm
3Z4S-LE VS-MCL35-
FN080/M42-10
F8 55 mm dia.
99.5 mm (0.025x) to
117.6 mm (0.50x)
M52
P0.75
0.025x 1050.0 mm
0.10x 70.4 mm
0.50x 3.8 mm
3Z4S-LE VS-MCL50/M42-
10
50 mm
F2.8 52 mm dia.
64.0 mm (0.05x) to
82.0 mm (0.40x)
M46
P0.75
0
.05x 94.1 mm
0.10x 24.6 mm
0.40x 2.0 mm
3Z4S-LE VS-MCL50-
FN056/M42-10
F5.6 52 mm dia.
64.0 mm (0.05x) to
82.0 mm (0.40x)
M46
P0.75
0.05x 188.0 mm
0.10x 49.3 mm
0.40x 3.9 mm
3Z4S-LE VS-MCL50-
FN080/M42-10
F8 52 mm dia.
64.0 mm (0.05x) to
82.0 mm (0.40x)
M46
P0.75
0.05x 269.0 mm
0.10x 70.4 mm
0.40x 5.6 mm
