Arranging Windows
81
3
Performing Test Measurement/Starting Operation
Vision System FH/FZ5 Series
User’s Manual (Z340)
Adding Window Objects
1 Right-click somewhere in the gray area outside the window objects and select the name of
the object to add.
Deleting Window Objects
FH/FZ5-11
1 Right-click the window object and click [Delete the window].
FZ5-L35/FZ5-6
1 Click in the upper right corner of the window
object.
Restoring a Layout to its Default Settings
1 Select the layout number for the layout to restore to its default settings, and click [Restore the
default setting]. The layout for the selected number is restored to its default settings.
To Exit Layout Modification Mode
1 Click [Finish] on the layout modification Window to end layout modification.
Changing the Layout Number from a Layout with a Hidden Top Menu
If you click [Finish] on a layout where the top menu display is hidden, the [Switch layout] button will
automatically appear in the lower right corner. Click the [Switch layout] button and switch to a layout number
where the [Top menu display] option is selected.
Saving the Layout in the Controller or a File
Saving the Layout in the Controller
After you end Layout Modification Mode, click the [Data save] button.
Restart the Sensor Controller to reflect the layout modifications that were saved.
Saving a File
Select [Save to File] from the [Function] menu. Under [Settings data], set the [Data to be saved] to [System
data] or [System + Scene group 0], specify the destination, and then click the [OK] button.
