Search Speed
For processing items to perform search processing such as [Search] and [Classification], you can specify the
search processing speed by through the model parameter items "Stable", "Precise", and/or "Skipping angle". If
the value specified for "Stab." or "Prec." is small or if the value for "Skipping angle" is large, the processing
speed can be increased since the amount of information for the models will be decreased during the search. In
contrast, if the values specified for "Stab." or "Prec." are large or if the value for "Skipping angle" is small, the
processing speed is slow because search is performed without the amount of model information being reduced.
Specify appropriate values for "Stable", "Precise", and "Skipping angle" according to the measurement
conditions.
Basic selection flow
Note
Does Measurement
object (workpiece)
rotate?
Rotation range of
measurement
object (workpiece)
yes
no
No rotation (CR)
Rotation (PT)
Rotation (CR)
narrow
All
Measurement time: Short
Measurement time: Long
Value for "Staple" / "Precise": Small
Value for "Skipping angle" : Large
Measurement precision: Low
Measurement precision: High
Value for "Staple" / "Precise": Large
Value for "Skipping angle" : Small
