Memory Display Image on PLC I/O
863
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
GX-Developer PLC I/O memory display image
As an example, if 3 data items, expression 0 (DATA0) = 1.000, expression 1 (DATA1) = 200.000, and
expression 2 (DATA2) = 1000.000, are output from FZ4, they are stored to the PLC Link area as
measurement data as follows.
*1: Data is stored to the PLC I/O memory as follows for a decimal number per channel.
DM1000 0 3392 31000
+3+2+1+0
16960 15
+5+4
