Arranging the Window Display
93
3
Performing Test Measurement/Starting Operation
Vision System FH/FZ5 Series
User’s Manual (Z340)
Image Mode List
You can change the following items on the Main Window (layout 0).
Item Description
Through
The latest image is always loaded from the Camera and displayed.
When a through image is selected, saved images cannot be called up for measurement.
Freeze (default)
The image that was scanned in the immediately preceding measurement is displayed. Images are
updated when measurements are performed.
Last NG
The latest NG error image resulting from an overall judgement is displayed.
The latest measurement results are always shown in the overall judgement and measurement time.
In this case, the overall judgement result and measurement time may conflict with the Camera image.
Also, during continuous measurements, the last NG image cannot be displayed.
In the following cases, saved images cannot be called up for measurement.
• When a through image mode is selected in unused image display pane.
• When a through image mode is selected in hidden image display pane.
• If a measurement trigger is input while using the multi-input function or immediately after BUSY is turned OFF (such as
while the display is being updated), the last NG image cannot be displayed.
• [Display Last NG Image] serves a similar function as a processing item for which error images can be saved. If this
processing item is used, the last NG image can be acquired without operation having any effect on operation.
