13-6
13.1.3 Communication Specifications
Tool port
Description
Interface RS232C
Transmission distance
15 m
Baud rate 2400,4800,9600,19200,38400,57600,115200 bit/s
Communication method
Half-duplex operation
Synchronous method Asynchronous communication method
Transmission format
Data length 7 bits / 8 bits
Parity: None/Even/Odd
Start code: STX / No STX
End code: CR / CR+LF / None / ETX
Stop bit: 1 bit / 2 bits
Order of data transmission Transmits from bit 0 character by character.
Communication function Computer link (Slave)
Modem initialization
General-purpose communication (In the RUN mode only)
USB port
Description
Standard (Baud rate)
USB2.0 Fullspeed
Communication mode
Computer link (Slave)
COM port (RS232C port)
Description
Interface
RS232C
Transmission distance
15 m
Baud rate 2400,4800,9600,19200,38400,57600,115200 bit/s
Communication method Half-duplex communication
Synchronous method
Start stop synchronous system
Communication format
Data length: 7 bits/8bits
Parity: None/Even/Odd
Start code: STX/No STX
End code: CR/CR+LF/None/ETX
Stop bit: 1 bit/2 bits
Order of data transmission Transmits from bit 0 character by character.
Communication function
Computer link (Master/Slave)
Modem initialization
General-purpose communication
MODBUS RTU (Master/Slave)
PC(PLC) link (A maximum of 16 units can be connected by converting
to RS485.)
Factory default
Baud rate
Data length
Parity
Stop bit
Tool port 9600 bit/s 8 bits Odd 1 bit
COM port (RS232C port) 9600 bit/s 8 bits Odd 1 bit
