15-8
FP0R
No. Name
Default
value
Descriptions
Tool
port
set-
ting
410
Unit No. setting
1
1 to 99
412
Communication
mode setting
Computer link
Computer link
General-purpose communications
Note2)
Selection of modem
connection
Disabled Enabled/Disabled
413
Communication
format setting
Data lenght
bit: 8 bits
Parity check:
“with odd”
Stop bit: 1 bit
Enter the settings for the various items.
- Data lenght bit: 7 bits/8 bits
- Parity check: none/with odd/with even
- Stop bit: 1 bit/2 bits
- The following setting is valid only when
the communication mode specified by
system register 412 has been set to
“General-purpose serial communication”.
- Terminator CR/CR+LF/None/ETX
- Header: STX not exist/STX exist
415
Communication
speed (Baud rate)
setting
9600 bps
2400 bps / 4800 bps / 9600 bps /
19200 bps / 38400 bps / 57600 bps /
115200 bps
420
Starting address for
received buffer of
general (serial data)
communication mode
4096 0 to 32764
421
Buffer capacity
setting for data
received of general
(serial data)
communication mode
2048 0 to 2048
COM
port
set-
ting
410
Unit No. setting
1
1 to 99
412
Communication
mode setting
Computer link
Computer link
General-purpose serial communication
PC(PLC) link
MODBUS RTU
Selection of modem
connection
Disabled Enabled/Disabled
413
Communication
format setting
Data lenght
bit: 8 bits
Parity check:
Odd
Stop bit: 1 bit
Enter the settings for the various items.
- Data lenght bit: 7 bits/8 bits
- Parity check: none/with odd/with even
- Stop bit: 1 bit/2 bits
- The following setting is valid only when
the communication mode specified by
system register 412 has been set to
“General-purpose serial communication”.
- Terminator CR/CR+LF/None/ETX
-
Header: STX not exist/STX exist
415
Communication
speed (Baud rate)
setting
9600 bps
2400 bps / 4800 bps / 9600 bps /
19200 bps / 38400 bps / 57600 bps /
115200 bps
416
Starting address for
received buffer of
general (serial data)
communication mode
0 0 to 32764
417
Buffer capacity
setting for data
received of general
(serial data)
communication mode
2048 0 to 2048
Note1) The communication format in a PLC link is fixed at the following settings:
Data length is 8 bits, odd parity, stop bit is 1.
The communication speed (baud rate) is fixed at 115200 bps.
Note2) The general-purpose communication with the tool port is available only in RUN mode. In PROG
mode, the computer link mode must be used regardless of settings.
