15-59
Num
-ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP2
FP2SH/FP10SH
Screen display instructions
F180
FP-e screen
display
registration
SCR
S1, S2,
S3, S4
Register the screen displayed on
the FP-e. 9
*1
F181 FP-e screen
display
switching
DSP S Specify the screen to be displayed
on the FP-e.
3
*1
Basic function instruction
F182 Time
constant
processing
FILTR S1, S2,
S3, D
Executes the filter processing for
the specified input.
9
*2 *3
F183
Auxiliary
timer (32-bit)
DSTM
S, D
Turn on the specified output and
R900D after
0.01 s. × set value.
7
*4
Data transfer instructions
F190
P190
Three 16-bit
data move
MV3
PMV3
S1, S2,
S3, D
(S1)→(D), (S2)→(D+1),
(S3)→(D+2)
10
F191
P191
Three 32-bit
data move
DMV3
PDMV3
S1, S2,
S3, D
(S1+1, S1)→(D+1, D), (S2+1,
S2)→(D+3, D+2), (S3+1,
S3)
→
(D+5, D+4)
16
Logic operation instructions
F215
P215
32-bit data
AND
DAND
PDAND
S1, S2,
D
(S1+1, S1) AND (S2+1,
S2)→(D+1,
D)
7
F216
P216
32-bit data
OR
DOR
PDOR
S1, S2,
D
(S1+1, S1) OR (S2+1, S2)→(D+1,
D)
12
F217
P217
32-bit data
XOR
DXOR
PDXOR
S1, S2,
D {
(S1+1, S1
12
) AND (S2+1, S2)} OR
{(S1+1, S1) AND (S2+1,
S2)}
→
(D+1, D)
F218
P218
32-bit data
XNR
DXNR
PDXNR
S1, S2,
D
{(S1+1, S1
12
) AND (S2+1, S2)} OR
{(S1+1, S1) AND (S2+1,
S2)}→(D+1, D)
F219
P219
Double word
(32-bit) data
unites
DUNI
PDUNI
S1, S2,
S3, D
{(S1+1, S1) AND (S3+1, S3
16
)} OR
{(S2+1, S2) AND (S3+1,
S3)}
→
(D+1, D)
Data conversion instructions
F230
P230
Time data
→
second
conversion
TMSEC
PTMSEC
S, D The specified time data ( a date
and time) is changed to the second
data.
6
*5 *6 *7 *7
F231
P231
Second
data
→
time
conversion
SECTM
PSECTM
S, D The specified second data is
changed into time data (a date and
time).
6
*5 *6 *7 *7
: Available, : Not available, : Not available partially
*1) This instruction is available for FP-e only.
*2) This instruction is available for FPΣ Ver. 3.10 or later.
*3) This instruction is only available for FP-X Ver.2.0 or later.
*4) This instruction is available for FP10SH Ver. 3.10 or later.
*5) This instruction is available for FPΣ 32k type.
*6) This instruction is available for FP-X Ver. 1.13 or later.
*7) This instruction is available for FP2/FP2SH Ver. 1.5 or later.FP10SH cannot be used.
