9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
4.17
FUEL LINE REMOVAL / INSTALLATION
(EVAP MODELS)
q
Fuel Supply Line
e
Retaining Clips
w
Fuel Purge Line
r
Zip Ties
1. Place a shop towel around the fuel line to catch any
dripping fuel.
2. To remove fuel line
q
, pull open tabs while moving
the clip out to release the line.
3. Release the fuel line from applicable retaining clips/
zip ties. See image/table above.
4. Remove fuel line from the vehicle.
5. To install the line, verify the connectors are clean and
free of debris.
6. Place the fuel line back over the fitting and slide
connector locking mechanism back into place. Verify
connector tabs snap back into place.
7. Turn the key on to prime the system. Check for
leaking at each end of the fuel line.
EFI / FUEL SYSTEM
