9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
ELECTRICAL COMPONENT LOCATIONS (FRONT)
3)
Fuse Box
3(
C4 Gauge
4*
Right Headlight
3!
12V Receptacle
4)
LED Dash Light
4(
Fan
3@
Instrument Cluster
4!
Pedal Position Sensor
5)
Left Accent Light
3#
AWD Switch
4@
SCM
5!
Right Accent Light
3$
Headlight Switch
4#
Brake Pressure Switch
5@
Voltage Regulator
3%
SCM Mode Switch
4$
Chassis Ground
5#
Voltage Regulator
3^
Key Switch
4%
Shock Actuator
5$
GPS Receiver
3&
EPS Power
4^
Diagnostic Plug
5%
AAT Sensor
3*
EPS Signal
4&
Left Headlight
5^
AWD Coil
ELECTRICAL
