8.52
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
9. Install the SCM / mounting plate assembly into the
vehicle. Torque mounting fasteners to specification.
IMPORTANT
A sticker with an arrow on the SCM indicates which side
MUST face the front of the vehicle.
TORQUE
SCM Mounting Plate Fasteners:
8 ft-lb (11 Nm)
10.Install the instrument panel cover. Torque fasteners to
specification.
TORQUE
Instrument Panel Cover Fasteners:
8 ft-lb (11 Nm)
DYNAMIX™ SYSTEM FEATURES
VEHICLE SPEED SENSITIVITY
The system continuously monitors the speed of the vehicle and adjusts to a base level of damping for a given vehicle
speed depending on the mode selected by the user.
CORNERING CONTROL
The system continuously monitors steering angle, lateral
acceleration, and vehicle yaw rate to provide enhanced
cornering control, reducing body motion for maximum
performance.
STEERING / SUSPENSION
