10.18
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
7. Click on the link shown above, save the file to your
hard disk and then double-click the icon to start the
update process.
NOTICE
Do not "run" or "open" the file from where they are.
Select "save" and download them to your PC before
running the install.
8. When the update is complete, the version shown on
the right side of the Digital Wrench® start-up screen
should match the update you just downloaded.
NOTICE
Versions and updates are subject to change.
DIGITAL WRENCH® COMMUNICATION
ERRORS
If you experience problems connecting to a vehicle or
any Digital Wrench® related problem, visit the Digital
Wrench® Knowledge Base for the most current
troubleshooting information, FAQs, downloads and
software updates at: http://polaris.diagsys.com/.
DIGITAL WRENCH DIAGNOSTIC
CONNECTOR
Located under the hood connected to a sealed plug
q
.
Follow these steps to connect the diagnostic interface
cable to the vehicle to allow Digital Wrench® use:
1. Assemble the SmartLink Module and attach the PC
Interface Cable to your laptop.
2. Remove the protective cap from the Digital Wrench®
connector.
3. Connect the Vehicle Interface Cable to the Digital
Wrench® diagnostic connector.
4. Turn the ignition key to the ‘ON’ position, select the
appropriate vehicle and wait for the status to display
‘Connected’ in the lower left corner of the screen.
5. Once connected, proceed with using Digital
Wrench®.
GUIDED DIAGNOSTICS
Guided diagnostics are available within Digital Wrench®
for all supported Trouble Codes (that is, any fault that will
turn on the ‘Check Engine’ indicator).
In addition, guided diagnostics are also available for
many other electrical sub systems.
Diagnostic procedures are added to subsequent versions
of Digital Wrench® as they become available. Check
your release version often and upgrade when available
to be sure you are using the most current software
available.
DIAGNOSTIC
