REAR FENDER / FENDER FLAIR
FENDER FLAIR REMOVAL
1. Remove four plastic rivets
q
and three Torx screws
w
from the rear fender flair
e
.
2. Remove rear fender flair from the vehicle.
FENDER REMOVAL
1. Remove two Torx screws from the PVT and/or Air
Intake cover/pre-filter.
2. Remove the PVT and/or Air Intake cover/pre-filter
r
(engine air intake shown).
3. Remove two plastic rivets
t
retaining the rear fender
y
.
4. Remove rear fender from the vehicle.
