9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
10.25
DIAGNOSTIC TROUBLE CODE LIST
Most EFI fault codes are caused by wiring issues. Rarely is an ECU or the sensor the cause of a DTC. Thoroughly test
the wiring related to the DTC before replacing any components. The best way to diagnose a wiring issue is to get the
vehicle up to operating temperature so there is some heat in the wiring. Connect the vehicle to Digital Wrench and go
to Data Display. Click on the Graph icon associated with the sensor that is tripping the DTC. Wiggle the wiring to that
sensor while watching the graph. The reading should be consistent while the wiring is being wiggled. Spikes up or
down indicate damaged wiring.
SPN FMI COMPONENT CONDITION DTC
29
2
Accelerator Position 2
Data Erratic, Intermittent or Incorrect
P1225
3
Voltage above normal
P1228
4
Voltage below normal
P1227
51
2
Throttle Position Sensor 1
Data Erratic, Intermittent or Incorrect
P0121
3
Voltage above normal
P0123
4
Voltage below normal
P0122
84
0
Vehicle Speed Sensor
Valid but above normal C1057
2
Data Erratic, Intermittent or Incorrect
P0503
C1058
10
Abnormal rate of change
C1068
19 Received network data-in error C1069
91
2
Accelerator Position 1
Data Erratic, Intermittent or Incorrect
P0225
3
Voltage above normal
P0228
4
Voltage below normal
P0227
96
2
Fuel Level Signal
Data Erratic, Intermittent or Incorrect
P0461
3
Voltage above normal
P0463
4
Voltage below normal
P0462
16 Valid but above normal P1462
18 Valid but below normal P1463
102
3
Manifold Absolute Pressure
Sensor
Voltage above normal
P0108
4
Voltage below normal
P0107
105 0
Intake Air Temperature
Sensor
Valid but above normal P1111
108
3
Barometric Pressure Sensor
Voltage above normal
P2229
4
Voltage below normal
P2228
110
0
Engine Temperature Sensor
Valid but far above normal P1217
2
Data Erratic, Intermittent or Incorrect
P0116
3
Voltage above normal
P0118
4
Voltage below normal
P0117
16 Valid but above normal P0217
162 2
Transmission Range
Invalid U108D
168
1
System Power
Valid but below normal P1563
3
Voltage above normal
P0563
C1063
4
Voltage below normal
P0562
C1064
190
0
Engine Speed
Valid but above normal C1059
2
Data Erratic, Intermittent or Incorrect
C1061
19 Receive network data-in error C1066
DIAGNOSTIC
