11.22
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
CARGO BOX
1. Remove both seats.
2. Remove the PVT pre-filter (driver side) and air intake
pre-filter (passenger side) assembly.
3. Remove the ROPS. Refer to Cab Frame Assembly
page 11.4 for reinstallation and torque info.
4. Remove the engine access panel and the panel
locking pin
q
.
5. Remove the 15 Torx screws
w
and two plastic rivets
e
in the bed of the cargo box.
6. Remove the seven Torx screws
w
on the cab side of
cargo box.
7. Remove both cargo box halves from the vehicle.
BODY / FRAME
