9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
6. Remove the air box through the cargo box access
panel.
AIR BOX INSTALLATION
1. Install the air box through the cargo box access
panel.
2. Install the intake hoses onto the air box. Tighten hose
clamps to specification.
TORQUE
Intake Hose Clamps:
35 in-lb (4 Nm)
3. Lift the cargo box enough to access the lower air box
mounting points. Install fasteners and torque to
specification.
TORQUE
Lower Air Box Mounting Fasteners:
8 ft-lb (11 Nm)
4. Install the cargo box fasteners previously removed.
Torque fasteners to specification.
TORQUE
Cargo Box Fasteners:
8 ft-lb (11 Nm)
5. Install engine access panel.
6. Install both seats.
ENGINE / COOLING SYSTEM
