10.26
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
SPN FMI COMPONENT CONDITION DTC
31 Condition exists P121C
523
2
Gear Sensor Signal
Data Erratic, Intermittent or Incorrect
P0914
4
Voltage below normal
P0916
628
12
ECU Memory
Bad intelligent device
C1073
13 Out of calibration C1601
636 2 Crankshaft Position Sensor
Data Erratic, Intermittent or Incorrect
P0335
651
3
Injector 1 (MAG)
Voltage above normal
P0262
4
Voltage below normal
P1262
5
Current below normal or open
P0261
652
3
Injector 2 (PTO)
Voltage above normal
P0265
4
Voltage below normal
P1265
5
Current below normal or open
P0264
731 1 Knock Sensor Valid but below normal P0326
1071
3
Fan Relay Driver
Voltage above normal
P1482
4
Voltage below normal
P1483
5
Current below normal or open
P1481
1127
0
Boost Pressure Sensor
Valid but above normal P0234
3
Voltage above normal
P0238
4
Voltage below normal
P0237
31 Condition exists P1234
1268 3
Ignition Coil Driver (MAG) Voltage above normal
P1353
1269 3
Ignition Coil Driver (PTO) Voltage above normal
P1354
1347
3
Fuel Pump Driver Circuit
Voltage above normal
P0232
4
Voltage below normal
P0231
5
Current below normal or open circuit
P0230
2629
3
Engine Turbo Compressor
Outlet Temperature
Voltage above normal
P1235
4
Voltage below normal
P1236
3056
2
Oxygen Sensor
Data erratic, intermittent or incorrect
P0130
3
Voltage above normal
P0132
4
Voltage below normal
P0131
3597
3
ECU Output Ignition / Supply
Voltage 1
Voltage above normal
P16A2
4
Voltage below normal
P16A1
3598
3
ECU Output Injection /
Supply Voltage 2
Voltage above normal
P16A9
4
Voltage below normal
P16A8
3599
3
ECU Output Supply Voltage
3
Voltage above normal
P17AA
4
Voltage below normal
P17AB
65590 7 Misfire Detected
Cylinder Not Identified
P0314
65591 7 Misfire Detected
Cylinder 1 (PTO)
P0301
65592 7 Misfire Detected
Cylinder 2 (MAG)
P0302
65613 2
ETC Accelerator Position
Sensor Outputs 1 & 2
Correlataion
Data erratic, intermittent or incorrect
P1135
516098
2
Suspension Mode Switch
Input (Dynamix only)
Invalid C1005
3
Short/Voltage too high
C1006
4
Short/Voltage too low
C1007
DIAGNOSTIC
